Simple Cutting-to-Length and Slitting Machine


Certificates

Certified with Multi-Patents; CE Certified , EUROPEAN quality standard

Machine Condition

New, A Grade quality

Operator

1 person

Decoiler Capacity

3t, 5t, 8t, 10t, 15t

Power Voltage

220V/380V/415V/460V

Products Usage

This machine is the accessorial equipment for roll forming machine or folding machine, which is used to slit coil sheet to strips, and transfer it to support it.

Equipment Color

According to customer’s requirements; normally Blue/White


Brief Introduction of Simple Cut to Length and Slitting Machine


This machine is the accessorial equipment for roll forming machine or folding machine, which is used to slit the coil sheet to strips and transfer it to support it. In order to get some nonstandard width length sheets.  It has many advantages such as low noise, stable running, simple operation, and nice appearance etc.


Working Flow of Simple Cut to Length and Slitting Machine


  • Coil Charging Car (optional)

  • Decoiler (passive/auto)

  • Filming Covering (optional)

  • Cutting to length

  • Slitter

  • Output supporter

Parameters of  Simple Cut to Length and Slitting Machine

Suitable coil width1000-1250mm
Material strength230-300Mpa
sheet coilMax. weight: 5T
Decoiler suitable coil I.D.Inner diameter: φ508 or 610
slitter8 pairs
slitted strip widthMin 60mm (adjustable.)
Suitable coil thickness0.4~1.2mm
Length tolerance+/- 2mm in 3M in length
Slitting speed10 M/min
Motor powerslitter power: 3 KW
Hydraulic motor power: 3 KW
Cuttingcut to length automatically
Power source380V/3phase/50/60 Hz (can meet your demand)
CertificatesCertified with Multi-Patents; CE Certified , EUROPEAN quality standard
Machine ConditionNew, A Grade quality
Operator1 person
Decoiler Capacity3t, 5t, 8t, 10t, 15t
Power Voltage220V/380V/415V/460V
Products UsageThis machine is the accessorial equipment for roll forming machine or folding machine, which is used to slit coil sheet to strips, and transfer it to support it.
Equipment ColorAccording to customer's requirements; normally Blue/White


Service and Terms of Simple Cut to Length and Slitting Machine


Prompt GoodsMost of models are in stock.
Fast Delivery30 days after receipt of payment and technical agreement
ManufacturerAll equipments are manufactured In-house.
Warranty20 months
Service1. Life long service;
2. All projects include engineering, drawings and project management and are treated similarly as a new metal forming equipment order.
3. quick maintenance and spare parts service
After-sales Service1. 7x24h before & after service team;
2. Experienced Engineers team for overseas market to handle all your troubleshooting and service needs for your roll forming, coil processing and tube equipment.
Payment TermsT/T, L/C
30% down payment upon order confirmation; balance before shipment
Place of OriginZhejiang, China (Mainland)
PackingStandard export packing
LOADING SIZENormally need 1x 20GP container.
